Introduction
I.Detection Part：
- The equipment can have the functions of locating the drone and the pilot for DJI's latest O4 video transmission.
- It has the function of receiving analog video transmission of FPV drones.
- Frequency band support: Supports the 25MHz - 6GHz frequency band.
- Key frequency band monitoring: 433MHz, 900MHz, 2.4GHz, 5.2GHz, 5.8GHz.
- Reconnaissance distance: ≥5 kilometers.
- Direction - finding accuracy: ≤10° (while following); ≤3° (while hovering).
- Reconnaissance sensitivity: ≥ - 115dBm (25kHz).
- Reconnaissance airspace: Capable of 360 - degree all - airspace reconnaissance.
- Adaptable communication modulation methods: FM, 2FSK, 4FSK, GFSK, MSK, BPSK, QPSK, 16QAM, 64QAM, OFDM, DSSS, FHSS.
- Power supply: AC100-240V.
- Reconnaissance modes: panoramic scanning and channel scanning.
- Working capacity: Capable of continuous operation 24 hours a day.
- Passive detection: Only passively receives without emitting any electromagnetic signals. Can detect the drone model and its electronic fingerprint.
- Accurate orientation: Can accurately determine the intrusion direction of the drone and indicate the target.
- Precise identification: Can precisely identify different drones of the same brand and model.
- Unattended operation: When the unattended mode is activated, it can automatically detect and alarm 24 hours a day.
- Black and white list: Can mark the black and white list with one click. Drones on the white list will not trigger an alarm.
- Full model library: Supports the full series of DJI drones, mainstream market brands, and DIY drones, covering more than 98% of the models on the market.
| Channel | Power | Function |
|---|---|---|
|
410MHZ-470MHZ |
50W |
UAV remote control frequency band |
|
830MHZ-940MHZ |
50W |
UAV remote control frequency band |
|
1180MHZ-1280MHZ |
50W |
UAV video transmission and positioning
frequency band |
|
1420MHZ-1460MHZ |
50W |
UAV image transmission frequency band |
|
1555MHZ-1655MHZ |
50W |
UAV positioning and navigation frequency band |
|
2400MHZ-2485MHZ |
100W |
UAV remote control and image transmission |
|
5150MHZ-5350MHZ |
50W |
UAV image transmission frequency band |
|
5725MHZ-5850MHZ |
100W |
UAV image transmission frequency band |
- 2. Jamming function: It can emit jamming signals to make the drone return or land in place (the drone supports return or forced landing function).
- 3. The time required from starting jamming to the drone being successfully jammed is ≤3 seconds.
- 4. Jamming distance: In an environment without obvious rain, snow, or fog (without obvious obstructions and without obvious electromagnetic interference), the device's jamming distance to the drone is not less than 1.5 kilometers.
- 5. Jamming angle: Horizontal 360°, pitch: -45° to 45°.
- 6. Precise strike: After networking with radio detection equipment and other devices, it can accurately strike the designated drone among multiple (no less than 2) drones of the same model, same working frequency band, and same direction without affecting the normal controlled flight of other non-designated drones (requires cooperation with radio detection equipment), and can precisely strike non-white list drones set by radio detection equipment.
- 7.Networking function: It can be networked with other equipment such as radio detection equipment through wired or wireless means.
- 8.Protection level: IP65.
- 9.Operating temperature: -40℃ to +55℃.
